AT28C256-15PC

Programmable Read Only Memory, DIP, -0.6V to +6.25V, Low Power Dissipation, Software Data Protection

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.98~0.98 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.98~0.98

PartNumber:: AT28C256-15PC

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 03+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ruth's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-08

From Other Seller

Part Number:AT28C256-15PC
US $0.98 - 0.98
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT28C256-15PC is a high-performance Electrically Erasable and Programmable Read Only Memory. Its 256K of memory is organized as 32,768 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the AT28C256-15PC offers access times to 150 ns with power dissipation of just 440 mW. When the AT28C256-15PC is deselected, the CMOS standby current is less than 200 mA.

Parametrics

AT28C256-15PC absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE and A9 with Respect to Ground: -0.6V to +13.5V.

Features

AT28C256-15PC features: (1)Fast Read Access Time - 150 ns; (2)Automatic Page Write Operation: Internal Address and Data Latches for 64-Bytes, Internal Control Timer; (3)Fast Write Cycle Times: Page Write Cycle Time: 3 ms or 10 ms Maximum, 1 to 64-Byte Page Write Operation; (4)Low Power Dissipation: 50 mA Active Current, 200 μA CMOS Standby Current; (5)Hardware and Software Data Protection.
