Product Summary
The LM25007MM is a 42V, 0.5A step-down switching regulator. The LM25007MM is a monolithic step-down switching regulator featuring all of the functions needed to implement a low cost, efficient, power supply. Capable of driving a 0.5Amp load over a 9V-42V input voltage range, this LM25007MM is easy to apply and is provided in the small MSOP-8 and the thermally enhanced LLP-8 packages. Ultra-fast transient response of the LM25007MM is achieved through the use of a constant on-time architecture with Vin feed forward. This feature provides an almost constant operating frequency over load and input voltage variations.
Parametrics
LM25007MM absolute maximum ratings: (1)VIN to RTN: 45V; (2)BST to RTN: 59V; (3)SW to RTN (Steady State): -1V; (4)ESD Rating. Human Body Model: 2kV; (5)BST to VCC: 45V; (6)BST to SW: 14V; (7)VCC to RTN: 14V; (8)All Other Inputs to RTN: -0.3 to 7V; (9)Storage Temperature Range: -65℃ to +150℃.
Features
LM25007MM features: (1)Integrated 0.74 ohm N-Channel MOSFET switch; (2)Guaranteed 0.5Amp output current; (3)Ultra-Fast Transient Response; (4)Up to 800kHz operation; (5)No control loop compensation required; (6)Vin feed forward provides constant operating frequency; (7)2% accurate 2.5V feedback from -40 to 125℃; (8)Highly efficient operation; (9)Intelligent current limit protection; (10)External shutdown control; (11)Thermal shutdown; (12)MSOP-8 and thermally enhanced LLP packages.
