MSM82C51A-2JS

USART, PLCC-28, –0.5 to +7 V, Wide power supply voltage range, data communication

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.95~0.95 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.95~0.95

PartNumber:: MSM82C51A-2JS

Brand:: OKI electronic componets - OKI | Pack: PLCC | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ruth's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-08

From Other Seller

Part Number:MSM82C51A-2JS
US $0.95 - 0.95
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MSM82C51A-2JS is a USART (Universal Synchronous Asynchronous Receiver Transmitter) for serial data communication. As a peripheral device of a microcomputer system, the MSM82C51A-2JS receives parallel data from the CPU and transmits serial data after conversion. This device also receives serial data from the outside and transmits parallel data to the CPU after conversion. The MSM82C51A-2JS configures a fully static circuit using silicon gate CMOS technology. Therefore, it operates on extremely low power at 100 mA (max) of standby current by suspending all operations.

Parametrics

MSM82C51A-2JS absolute maximum ratings: (1)Power Supply Voltage: –0.5 to +7 V; (2)Input Voltage: –0.5 to VCC +0.5 V; (3)Output Voltage: –0.5 to VCC +0.5 V; (4)Storage Temperature: -55 to +150 ℃; (5)Power Dissipation: 0.9 W.

Features

MSM82C51A-2JS features: (1)Wide power supply voltage range from 3 V to 6 V; (2)Wide temperature range from -40℃ to 85℃; (3)Synchronous communication upto 64 Kbaud; (4)Asynchronous communication upto 38.4 Kbaud; (5)Transmitting/receiving operations under double buffered configuration; (6)Error detection (parity, overrun and framing); (7)28-pin Plastic DIP (DIP28-P-600-2.54): (Product name: MSM82C51A-2RS); (8)28-pin Plastic QFJ (QFJ28-P-S450-1.27): (Product name: MSM82C51A-2JS); (9)32-pin Plastic SSOP(SSOP32-P-430-1.00-K): (Product name: MSM82C51A-2GS-K).
